Online Continuous Gas Analysis System

TH-2000C Online continuum Gas Analysis System

Features:

● ISO, CE, FCC, ROHS Probatus

IP66 with explosion-probation & IMPERVIUS design

inaedificata in summus efficientiam duos scaena condensationis anti-humidificationis et pulveris remotionis pretreatment systema

Mensurae altae accurate mensurare ultra-humilem concentrationem potest

● Real-time ostentationem cuiusque Gas componentis concentration curva

● Multi modi mensurae: automaticae et manuales modi;

● in fabrica calefactione fabricata, sponte incipit munus calefacere ad caliditatem frigiditatem, ut analysris in locis frigidis gravibus adhiberi possit.

Automatic zeroing and calibration function

Lata temperatura et magna Multi-angulus flip TFT color screen ostentus

Linux operating ratio

Industrial summus celeritate embedded industriae computatrum

instructus humano-computer interface divitiis, mus subsidiis, U orbis, tincidunt, touchpad, typographo et aliis instrumentis

Ad duris conditionibus apta operando, facile ad operandum

● Culpa auto-reprehendo munus, culpam famam post detectionem generat, conveniens usuario sustentationi

Integrated integrated micro thermal printer or external Bluetooth wireless printer

Magnae capacitatis notitia repono

libitum automatic backflush ratio

Latin sampling spatium est XXX ~ XL metris, ad libitum LXX metris

Gas fiue deprehensio et analysis altioris temperatus debet esse nativus

SPECIFICATIONS

Single gas detector: CH4 & H2S

Deprehensio principium:

CH4: Princeps senatus IR sensor;

0-100%VOL, 0.01%VOL resolution

H2S:Professional biogas sensorem electrochemicum;

0-1000ppm, 0.1ppm resolutio

● Linearity: ≤±1.5% (F.S)

Repeatablility：±0.5%

● Nulla calliditate span：±2%F.S./7 dierum

●Perflua operation±2%F.S./7 dierum

Temperature range：- 40℃~70℃，≤95%RH

Responsorium tempus: 45S

Deprehensio modum: genus exantlaretur

Sampling temperatus: -40℃ ~ 600℃ (vexillum)

optional: -40℃~800℃, -40℃~1300℃;

superior temperatus deprehensio et analysi necesse est esse nativus

Sampling humiditas: 0 ~ 99% RH

praesidium campester: IP66

● Sampling procul: vexillum XXX ~ XL m, libitum usque ad 70m

fluxus Sampling: aptabilis, 2 L/m (vexillum), 4 L/m (optional); 10 L/m (libitum)

Opus intentione: 220VAC, 50HZ

● Output signum: 4~20mA, RS485, multi-alvei passivi noti

ad libitum: wireless transmissio, retis transmissio

Dimensiones: 800mm * 500mm * 340mm

● Display modus: 9-inch tactu color screen display

Printing modus: ad libitum wireless Bluetooth printer

● Terror modus: ad libitum integratus sonus et terror lucis externi

Warranty time: 1 year
